| Marke | Nuova Fima |
| Produkt | 1.20.3.A.G.-ABFD.41M.L02 0-10 PSIG |
| Beschreibung | Pressure Gauge 6" Dial size. Range 0-10 PSIG, 1/2" Bottom Con. |
| Interner Code | IMP15347 |
| Gewicht | 1 |
Entdecken Sie die überlegene Qualität und Leistung von Nuova Fima 1.20.3.A.G.-ABFD.41M.L02 0-10 PSIG mit Impexron GMBH in Schweiz . Egal, ob Sie nach Zuverlässigkeit oder Effizienz suchen, dieses Produkt erfüllt alle Ihre industriellen Bedürfnisse.
Der 1.20.3.A.G.-ABFD.41M.L02 0-10 PSIG ist so konzipiert, dass er in verschiedenen Anwendungen optimale Leistung und Haltbarkeit bietet. Bekannt für seine hochwertige Konstruktion und innovativen Funktionen, ist er die bevorzugte Wahl für Fachleute.
Hauptmerkmale des 1.20.3.A.G.-ABFD.41M.L02 0-10 PSIG :
Bei Impexron GMBH bieten wir den 1.20.3.A.G.-ABFD.41M.L02 0-10 PSIG zu wettbewerbsfähigen Preisen und mit den schnellsten Lieferzeiten in Schweiz . Unser Expertenteam steht Ihnen bei allen Fragen zur Verfügung und bietet maßgeschneiderte Lösungen, die Ihren spezifischen Anforderungen gerecht werden.
Warum Impexron GMBH wählen?
Erhalten Sie noch heute Ihr Angebot! Bereit, Ihre Abläufe mit dem 1.20.3.A.G.-ABFD.41M.L02 0-10 PSIG zu verbessern? Kontaktieren Sie uns jetzt für ein personalisiertes Angebot. Füllen Sie das untenstehende Formular aus oder senden Sie uns eine E-Mail mit Ihrer Anfrage. Lassen Sie uns Ihnen helfen, eine kosteneffiziente und qualitativ hochwertige Wahl für Ihr Unternehmen zu treffen.
Important note: Although weNuova Fima -Products areImpexron GMBH not an authorized dealer . All rights are reserved by the manufacturers and their official partners.
Pressure gauge Type: 01.20.3.A.G.ABFD.41M.L02 Execution: All st.st. bourdon tube pressure gauge, SOLID FRONT, Glycerine filled Mounting: direct Diameter: DN 150 Connection: 1/2" BSP male in st.st. AISI 316 L Range: 0-15 psi Case material: bayonet-lock case in st.st. AISI 304 Window material: safety glass Accuracy: Kl. 1.0 with adjustable pointer
pressure switch
00020 201071825 GAUGE:PRESS;0-10KG/CM2,1/8IN,NPT,2-1/2IN GAUGE: PRESSURE RANGE: 0-10 KILOGRAM PER SQUARE CENTIMETER CONNECTION SIZE: 1/8 IN CONNECTION: NATIONAL PIPE THREAD FACE SIZE: 2-1/2 IN CONNECTION LOCATION: LOWER MANUFACTURER: NUOVA FIMA MODEL NUMBER: 52240251060000 *PHOTOS ATTACHED* 00030 201090588 TRANSDUCER:ELECTRO PNEUMATIC,4 TO 20MA,%
TEMPERATURE GAUGE, RANGE 0-160C, APPLICABLE SERIAL NO 2758/02
TEMPERATURE GAUGE, RANGE 0-200C, APPLICABLE SERIAL NO 2758/06
thermostat
(Test- und Konformitätserklärung 3.1 von NUOVA FIMA)
DDM-DM-D-DIVERS 02.16.1.A.G.0/600 mbar.43M.C.S31.R10
Statistische Warennummer: 90262040 Differential pressure gauge Type: 02.16.1.A.G.0/600 mbar.43M.C.S31.R10 Execution: with double diaphragm Mounting:direct or with back flange diameter: DN 150 Lower Connections: 1/2" NPT male in st.st. AISI 316L Range: 0- 600 mbar static pressure: max. 100 bar Case material: bayonet-lock case in st.st. AISI 304 window material: glass case filling: glycerine 2" Stackes bracket accuracy: Kl. 2,5 %
Statistische Warennummer: 90268020 Druckmessumformer Typ: 08.S18 NUOVA FIMA Code: 08.S18-0/40 bar-23M-1 Messbereich: 0-40 bar Ausgang: 4-20 mA, 2 Leiter Hilfsenergie: 8-30 VDC Genauigkeit: 0,5% FSO nach IEC 60770 Prozessanschl.: 1/4 NPT Aussengewinde Elektr. Anschluss: Steckverbindung DIN 43650 Schutzart: IP 65
DMU-S-D-001009 08.S18 08 / S18 AAFE = 0-16 BAR 23M 1 = OUTPUT: 4...20 MA- 2 WIRES , SUPPLY: 8...30
Pressure sensor Execution: pressure sensor with ceramic cell
Pressure sensor Type: 08.S18 Execution: pressure sensor with ceramic cell Accuracy: 0,5% F.S.V acc. to IEC 60770-Limit point Electrical connection: Male and female plug DIN 43650 Specification Code acc. to Data-sheet 08 = Electronics S18 = Pressure transmitter 0-600 bar = range 43M = process connection: 1/2 NPT male 10E = output: 4-20 mA, 2 wire / supply: 10..30 VDC Please check the process connection and output. It was not specified in the inquiry.
Statistische Warennummer: 90262040 Pressure transmitter with local readout for homogenizer Type: 08.MOM.3.A.E.AAFZ (0...400 bar).422.1. Filling liquid: dielectric oil Mounting: direct, bottom connection Dial diameter: 100 mm Process connection: SA422 Range: 0-400 bar case in st.st. AISI 304 glass window Output: 4-20 mA Power Supply: 10...30Vcc with logo "NUOVA FIMA" and "LR"
Pressure gauge Type: 1.20.3.A.E.41M. Execution: all st.st. bourdon tube pressure gauge Solid front execution, glycerine filled Mounting:direct dial diameter: DN 100 Range: 0-16 bar Case material: bayonet-lock case in st.st. AISI 304 window material: safety glass accuracy: Kl. 1,0 with diaphragm seal MGS 9/2B 4.2B0.9.9.43F.41F.BAI diaphragm in Hastelloy C276 process connecion in Hastelloy C276 process connection: 1/2" NPT female
(Pressure transmitter with local readout for homogenizer Mounting: direct, bottom connection Dial diameter: 100 mm Process connection: SA167 Range: 0-600 bar case in st.st. AISI 304 glass window Output: 4-20 mA Power Supply: 10...30Vcc with calibration certificate (C01))
KAMERA
Statistische Warennummer: 90262040 Pressure gauge Type: 01.27.1.A.I Execution: Laboratory bourdon tube test gauge Mounting: direct Diameter: DN 250 (10") Connection: 1/2 NPT male bottom in st.st. AISI 316 Range: 0-40 bar Case material: Aluminium, black coated External zero-adjustment High precision movement mounted on ball bearing Dial: Anti-parallax mirror Pointer: balanced, antiparallax knife-edge micrometer, adjustable Window material: Plexiglas Accuracy: Kl. 0,1 Specials: factory test certificat, traceable to international Standard
range 0-250 bar
(version "all stainless steel": DN 63) 1.18.3.DC0/16 BAR.21M
(Pressure gauge Type: 01.M2.3-D-E-0/400 bar-41M-04D.BM2.E Execution: all st.st. bourdon tube pressure gauge MCE18/3/E oil filled with double electric contact Mounting: with front flange diameter: DN 100 Connection: 1/2" BSP back in st.st. AISI 316L Range: 0-400 bar Case material: bayonet-lock case in st.st. AISI 304 window material: Plexiglas contacts: First contact opening, second contact opening on rising pressure, magnetic snap action)
Over pressure protection MP 4/8A in st.st. AISI 316 5.48A.5.41M.41F setting: 3....15 psi process connection : 1/2" BSP male gauge connection: 1/2" BSP female
MGS18 1.18.2.A.E-.AAFB.43M.C40.T32
Manometer
1.18.3.A.E.---.DAE7.41M.KCS ALL ST. ST. PRESSURE GAUGE, MODEL MGS18. 4" (100 MM) CASE DIAMETER. BOTTOM CONNECTION., RANGE 0...6 BAR/PSI, 1/2" BSP MALE PROCESS CONNECTION, ALUMINIUM DIAL, WHITE BACKGROUND WITH BLACK MARKINGS AND FIGURES, ST. ST. CASE AND BAYONET RING, DIRECT MOUNTING, ST. ST. PRECISION MOVEMENT, BLACK ALUMINIUM POINTER, ACCURACY ±1,0%, GLYCERINE FILLING, IP67 PROTECTION DEGREE, TEMPERED GLASS WINDOW, ST.ST. RESTRICTOR, MOUNTING WITH DIAPHRAGM SEAL
A 106 GR B carbon steel process connection 1/2" BSP male gauge connection: 1/2" BSP female
o. 3/20800420/10 Flow: 23,000 Nm3 H: 760 mbar
Thermometer, ½” Q: 100 0-150
TB899 (6.TB8.9.9.F.ATFT.43M.7)
BIMETALL-THERMOMETER
